      PowerLeader AI Storage PLStor A9600 Data sheet

      PowerLeader PLStor A9600: new-gen high-performance AI storage for AI, with extreme performance—36 NVMe SSDs, 1105.92TB raw capacity, 160GB/s bandwidth, 4 million IOPS per chassis; up to 32-controller scale-out for 10PB capacity. PowerLeader PLStor A9600 high-performance AI storage: new control-data separated architecture, 32-controller scalable for trillion/ten-trillion parameter multi-modal models. Supports AI-native vectors, tensors, KV Cache; built-in vector search accelerates retrieval, reduces inference "hallucinations"; KV Cache cuts latency, boosts efficiency—one storage for full AI training-inference.

      Functional features
      Extreme performance

      PLStor A9600 new-gen AI storage: DataTurbo engine enables kernel-mode direct storage access/caching, cutting memory usage by 50%, delivering 160GB/s per-chassis bandwidth and over TB-level cluster bandwidth. NDS direct NPU access creates optimal path, bypassing protocols, eliminating copies for 30% performance boost.


      Flexible Scalability

      PLStor A9600 new-gen AI storage: new hardware architecture, starting with 2 controllers, scaling to 36 per cluster (10PB capacity) with high performance/density.

      PLStor A9600 new-gen AI storage meets diverse ecosystems via file, object*, vector protocols, covering full AI workflow (data aggregation, preprocessing, training, inference) with zero data copy to accelerate model iteration.

      PLStor A9600 new-gen AI storage features SmartQuota (file system quota tech), letting admins control storage for directories/users/groups, limiting usage to prevent overoccupation and maximize storage value.


      Intelligent inference

      PLStor A9600 new-gen AI storage: supports new data paradigms (NAS, objects, vectors, graphs) with high-performance multimodal retrieval, excelling in RAG and Unified Cache acceleration. Built-in multimodal knowledge base with leading QPS for efficiency and accuracy.

      Unified Cache offers KV Cache multi-level caching, a PB-level shared pool, flexible allocation—cuts first-token latency by 78%, boosts inference throughput by 60%. Sparse attention enables ultra-large model context windows for accurate, fast, scalable central inference.

      Technical specifications

      Model

      PLStor A9600

      Hardware Architecture

      Disk and controller integration

      Maximum Raw Capacity per Controller Enclosure

      1105.92TB

      Height of Each Controller Enclosure

      2U

      Controllers per Controller Enclosure

      2

      Disks per Controller Enclosure

      36

      Processors per Controller

      Two Kunpeng 920 processors

      Maximum Memory per Controller

      512GB

      Data Disk Type

      Palm NVMe SSD

      Network Type

      25/100 Gb/s TCP/IP

      25/100 Gb/s RoCE

      Key Features

      Quota (SmartQuota), Quality of Service (SmartQoS), inference acceleration (Unified Cache), end-to-end data integrity check (DIF)

      Enclosure Dimensions

      (H x W x D)

      86.1mm x 447mm x 950mm(including the cover)

      Operating Temperature

      –60 m to +1800 m altitude: 5°C to 30°C (cabinet)/35°C (enclosure)

      1800 m to 4000 m altitude: The max. temperature threshold decreases by 1°C for every altitude increase of 220 m

      Operating Humidity

      10%~90%R.H.



      Service and Support

      For more information, please visit https://www.wuqingbo.com/

      Mailing address: 16th Floor, Building B, Block 7, Baoneng Science and Technology Park, No. 1 Qingxiang Road, Longhua New District, Shenzhen

      PowerLeader Computer reserves the right to change product specifications or other product information (including but not limited to product weight, appearance, size or other physical factors) without prior notice; the information mentioned in this document is subject to change due to product upgrades or other reasons, and no further notice will be given. All product images in this document are based on the actual products.

      This material is for reference only and does not constitute a commitment in any form.
